Description

ZEON 8 SPECS/PART NUMBER
– Part number: 88980
– Rated line pull: 8000 lbs. (3630 kg) single-line
– Motor: 12V DC, series wound
– Electrical controls: Contactor
– Remote Control: Remote switch, 12′ (3.7m) lead
– Geartrain: 3-stage planetary
– Gear ratio: 162:1
– Clutch (freespooling): Rotating ring gear
– Brake: Automatic mechanical cone
– Drum diameter/Length: 3.15″/9.0″ (80mm/229mm)
– Weight (kit shipping): 94 lbs. (42 kg)
– Rope: 5/16″ x 100′ (8mm x 30.5m) steel
– Fairlead: Roller
– Recommended Battery: 650 CCA minimum for winching
– Battery leads: 25mm gauge, 72″ (1.83m)
– Finish: Satin-black powder coat
– Warranty: Limited lifetime
