Oneway Disc Plough Trailed ? SDP10

Oneway Disc Plough Trailed ? SDP10

Close-up of a lime spreader machine in action on a farm.
Model No Discs Mass?(kg) Maximum Working Width(m) Tyres Disc Spacing?(mm) Average Tractor Req.(kW)
SDP 10-10 10 2.06 9.00/20 254 45 ? 55
SDP 10-12 12 2.52 9.00/20 254 50 ? 65
SDP 10-14 14 2.98 9.00/20 254 60 ? 70
SDP 10-16 16 3.44 9.00/20 254 70 ? 80
SDP 10-18 18 3.89 9.00/20 254 80 ? 90
SDP 10-20 20 4.35 9.00/20 254 90 ? 110
SDP 10-22 22 4630 4.81 9.00/20 254 110 ? 120
SDP 10-24 24 5270 5.27 9.00/20 254 120 ? 135
SDP 10-26 26 5.73 10.00/20 254 135 ? 155
SDP 10-28 28 6.18 10.00/20 254 155 ? 170
SDP 10-30 30 6.64 10.00/20 254 160 ? 185



Description

The Erdvark Trailed Oneway Plough is perfect for undercutting stubble, plant material, weed control and seedbed preparation. The Oneway works excellent in rocky conditions.

  1. The Erdvark Oneway Plough has excellent penetration ability due to effective penetrating angles. The ploughing action is better for covering of plant material than that of the disc harrow.
  2. The Oneway is available in 254 or 305 mm disc spacing.
  3. Heavy duty axles and taper roller bearings on wheels and plough disc hubs.
  4. Plough disc automatic break-away and reset with spring-loaded mechanism of which break-away force can be adjusted.
  5. Erdvark modern steering mechanism makes left and right hand turns possible.
  6. Erdvark?s very effective and simple tilting of disc frame to take in and out of ploughing, no frame raising as in older fabrications.
  7. Every plough disc has independent spring loaded axles which make it ideal for stumps and rocky conditions.
  8. Alternative discs can be removed for fallowing.
  9. Erdvark guarantees that no dust and sand can enter bearing hubs under normal working conditions due to Floating Duo-cone seals.
  10. Easy adjustments on steering and drawbar to ensure accurate plough settings.
  11. Replaceable wear bushes facilitate easy maintenance and reduce costs.
