BPI V-8, V-10 & V-12 SERIES

BPI V-8, V-10 & V-12 SERIES

Close-up of a lime spreader machine in action on a farm.
STOCK CODE MV-8TOL MV-10TOL MV-12TOL
WORKING WIDTH 5 800mm 6 700mm 7 800mm
NUMBER OF WHEELS 8 PIECES 10 PIECES 12 PIECES
NUMBER OF TINES PER WHEEL 40 PIECES 40 PIECES 40 PIECES
OPERATING SPEED 8-22km/h 8-22km/h 8-22km/h
TRANSPORT WIDTH 2 800mm 2 800mm 2 800mm
REQUIRED POWER 45kW 50kW 55kW
TOTAL WEIGHT 600kg 680kg 740kg

Description

  • The V-8, V-10 or V-12 is aimed at the farmer of a more commercial machine
  • The V-series with 8, 10 and 12 ground wheels – available with 40 x 7mm spring tines on each wheel -for medium to large sized areas, including any uneven fields
  • All finger wheels are spring-loaded which allows each finger wheel to adapt to the ground
  • The windrow width is easily adjustable using the cranks on the last two finger wheels on the machine
  • The centre wheels are positioned to uplift the material that has been compacted by the tractors wheels and fed to the side rows
  • The Rakes included in this series have an adjustable working width
  • The frame is very flexible and robust with a fixed draw bar in the back
