BPI AUTO RESET HEAVY DUTY RIPPER / SUB SOILER 350 & 550 SERIES

BPI AUTO RESET HEAVY DUTY RIPPER / SUB SOILER 350 & 550 SERIES

Close-up of a lime spreader machine in action on a farm.
STOCK CODE MARR 5 MARR 7 MARR 9 MARR 11 MARR 13
SPECIFICATIONS 5 TINE 7 TINE 9 TINE 11 TINE 13 TINE
TOTALWIDTH 2 500mm 3 000mm 3 900mm 4 700mm 5 600mm
WORKING DEPTH 200-350mm 200-350mm 200-350mm 200-350mm 200-350mm
WORKING WIDTH 1 200-1 800mm 1 800-2 700mm 2 400-3 600mm 3 000-4 500mm 3 600-5 400mm
DEPTH CONTROL WHEELS 195 x 14″ 195 x 14″ 195 x 14″ 195 x 14? 195 x 14?
REQUIRED POWER 60-70kW 85-90kW 110-120kW 130-140kW 160-180kW
STOCK CODE MARR 5 / 550 MARR 7 / 550 MARR 9 / 550 MARR 11 / 550 MARR 13 / 550
SPECIFICATIONS 5 TINE 7 TINE 9 TINE 11 TINE 13 TINE
TOTAL WIDTH 2 500mm 3 000mm 3 900mm 4 700mm 5 600mm
WORKING DEPTH 200-550mm 200-550mm 200-550mm 200-550mm 200-550mm
WORKING WIDTH 1 200-1 800mm 1 800-2 700mm 2 400-3 600mm 3 000-4 500mm 3 600-5 400mm
DEPTH CONTROL WHEELS 195 x 14? 195 x 14? 195 x 14? 195 x 14? 195 x 14?
REQUIRED POWER 135-150kW 175-190kW 225-245kW 275-300kW 325-350kW

Description

  • Two models are available with working depths from 300mm up to 550mm deep
  • The shape of the tines provides good penetration in hard, dry soil conditions. Components are heat-treated to stand up to the tough conditions these Rippers / Sub Soilers work in
  • The auto-reset tines and auto reset leaf spring protection maximises strength and durability in tough conditions. In hitting an obstruction, individual leaf springs allow to trip and ride over the obstacles, returning to their original position
  • Tine spacing of 300mm is effective in most conditions, but tine position can be adjusted to suit different situations
  • The ?bolt-on? bracket provides a flexible construction with possibilities to adjust the tine spacing and have the option to increase the number of tines, enabling the user to rip / sub soil the land completely
  • A robust roller is available that breaks up clods and seals in moisture
