BPI 400LT-10M / 600LT-12M & 1000LT-14M

BPI 400LT-10M / 600LT-12M & 1000LT-14M

Close-up of a lime spreader machine in action on a farm.
STOCK CODE MBS400 / 10 MBS600 / 12 MBS1000 / 14
TANK CAPACITY 400 600 1 000
TOTAL WIDTH 1 300mm 1 300mm 1 500mm
TOTAL LENGTH 900mm 900mm 900mm
TOTAL HEIGHT 1 250mm 1 350mm 1 400mm
PUMP TYPE DIAPHRAGM DIAPHRAGM DIAPHRAGM
BOOM 10m 12m 14m
NUMBER OF REGULATOR OUTLETS 3 3 5
PRESSURE SAFETY VALVE STANDARD STANDARD STANDARD
TANK MIXER STANDARD STANDARD STANDARD
TANK POLYETHELEN POLYETHELEN POLYETHELEN
TOTAL WEIGHT STANDARD(WITHOUT BOOM) 92kg 92kg 115kg
PTO 540rpm 540rpm 540rpm
REQUIRED POWER 45-50kW 45-50kW 60-65kW

Description

  • This mounted type 400, 600 and 1 000ℓ Boom Sprayer is used to drive the pump for multi-purpose plant protection
  • Sprayers come fitted with T-Jet or conical nozzles on booms
  • Spraying is essential after planting to control weeds, insects and diseases which can affect the health of plants like: wheat, barley, sorghum, corn, canola, cotton, sunflower and all vegetables crops etc
  • Boom Sprayers are ideal for plant protection applications such as herbicide, pesticide, fungicide etc
  • Extra hoses and spray guns can be fitted as optional extras
  • Extra hoses allows for spraying trees, specific problem areas and fire-fighting
  • The booms of the Sprayers are manufactured with different sizes from lengths of 10m, 12m and 14m
  • The booms are either mechanical as standard, or hydraulic lifting as an optional system
  • Polyethylene tanks are standard on all Boom Sprayers
  • Outer wing breakaway returns to spraying position if in contact with an obstruction
  • Compact design and fold for narrow transport width and height, along with standard wheels on the bottom of the main frame for easy storage
  • Powder coated or galvanised frames and booms are available which gives the machine rust free boom sprayer
  • Suction hose with filter to fill the tank with ease from any water source like a river, dam, and reservoir
  • Powder coated or galvinised
