BPI 175 TRAILED COMBINE

BPI 175 TRAILED COMBINE

Close-up of a lime spreader machine in action on a farm.
STOCK CODE A175A01
MASS 1 700kg
GRAIN TANK CAPACITY 1 600kg
TRACK WIDTH 2 200-2 800mm
TYRES 400 / 60 / 15.5″
OPERATING SPEED 4-8km/h
PTO SPEED 540rpm
REQUIRED POWER 35-60kW
WIDTH 2 400mm
LENGTH 5 200mm
HEIGHT 3 520mm
HEIGHT WITHOUT ELEVATOR 2 620mm
HARVESTING OUTPUT ? 4 TON/h
HEADERS
A175B07 A17B03
1 ROW 2 ROW
AUGER HEADER AUGER HEADER
A175B04 A175B08
1.5 m 1.5 m
SUNFLOWER HEADER SOYA BEAN HEADER
A175B09
SOYA BEAN
PULLY KIT

Description

  • The 175 model Trailed Harvester is available with headers for harvesting maize, soya beans, sorghum and sunflower
  • The 175 Combine has a unique intake and cleaning
  • The main rotor with threshing beaters, enclosed by sieves, is angled to a specific degree to allow threshed crop to slide down and through the sieve to be collected in the holding hopper
  • The secondary rotor allows more threshing, to remove as much unwanted material as possible
  • The cleaning mechanism has a built in blower system, to blow out chaff, husks and leaves from the threshed crop
  • The working speed of the 175 Trailed Harvesters is 4-8km/h and is able to harvest 4ton/h
  • The 175 can be fitted with a chaff chute to collect leaves and husks in a trailer to be used as animal feed
  • The machine is known for its high efficiency and has established itself in a leading position in both domestic and international markets
